RRP 2,820.10 £ incl. VAT
| Article number | 2309804 |
|---|---|
| MATERIALS HANDLED | Enamels, primers, varnishes, impregnations |
| PRICE CATEGORY (CAT. 1-5) | Category 1 |
| MAX. NOZZLE SIZE AT 15 MPa | 0.013" |
| MAX. DELIVERY RATE | at 12 MPa 0.9 l/min |
| MAX. OPERATING PRESSURE | 25 MPa |
| WEIGHT | 9kg |
| POSSIBLE SUCTION SYSTEMS (ACCESSORIES MAY BE REQUIRED) | Rigid suction system Technology |
| TECHNOLOGY | Piston pump |
| DRIVE | Pneumatic |
| EXPLOSION PROTECTION | Yes |
| MULTIPLICATION RATIO | 40:1 |
| VOLUME FLOW PER DOUBLE STROKE | 15 cm3 |
| VOLUME FLOW (60 double strokes) | 0.9 l/min |
| MAX. VOLUME WITH FREE OUTLET | 2.7 l/min |
| AIR INLET PRESSURE | 0.65 MPa |
| AIR CONSUMPTION PER DOUBLE STROKE AT 0.6 MPa | 3.9 nl |
| SOUND PRESSURE LEVEL AT 0.6 MPa AIR INLET PRESSURE | 74 db(A) |
